This page was created to provide quick access to information concerning the DMX based designs of RPM
DMX4SSR

4 channels
on-board SSRs
DMX16SSR

16 channels
on-board SSRs
DMX16SSR PCBOARD.JPG
DMX8-DCSSR

8 channels
on-board Dimmable DC SSRs

For LED Portafloods, MiniMighty
LED Floods, LED MR16's, etc.
DMX16-DCSSR

16 channels
on-board Dimmable DC SSRs

For LED Portafloods, MiniMighty
LED Floods, LED MR16's, etc.
DMX16SSR Completed.JPG
Grinch/595 DMX Dimmer

Provides dimming capability
to Grinch and Olsen 595 boards
Grinch DMX Dimmer V2.jpg
USB to DMX Adapter
(USB to DMX dongle)

Enttec USB Pro Compatible
RPM 4 Port e1.31 Bridge

E1.31 (Ethernet)
to four DMX universes
